• LIGHT SOURCE

  • 1150 W proprietary LED light engine
  • 84 x 20 W white LEDs
  • Minimum LED lifetime: >50,000 hours (see specs for further details)

  PHOTOMETRIC DATA

  • Light Engine Luminous Output: 90,000 lumens
  • Fixture Luminous Output: 63,500 lumens
  • Peak Luminous Intensity: 5,000,000 cd
  • CCT: 6000 K (+/- 250 K)

  OPTICS

  • 220 mm Front Lens
  • 1:7 zoom range (6.8° - 47.5° beam angle)

  DYNAMIC EFFECTS

  • 0 - 100% continuous dimming and strobe effects
  • Choice of four dimming curves
  • CMY color mixing
  • Color temperature control (6000 - 2850 K)
  • Color wheel with six interchangeable dichroic filters, including a Spectral Enhancement Filter
  • 1:10 Zoom (hyper zoom); 1:7 Zoom (native zoom)
  • Motorized frost
  • Iris
  • Variable edge control
  • Pan: 540°
  • Tilt: 268°
  • P3 videomapping of fixture color and/or intensity (10 segments)
  • Pre-programmed effects: Two ranges of pre-programmed FX

  COOLING AND NOISE

  • Low noise cooling system
  • User-selectable output vs. sound level control

  CONSTRUCTION

  • Height (head straight up): 848 mm (33.4 in.)
  • Height (maximum): 867 mm (34.2 in.)
  • Weight: 39.0 kg (86.0 lbs.)

  CONTROL

  • DMX-512 in/out
  • Ethercon in/out for P3, Art-Net, sACN
  • Built in Ethernet switch with fail-safe bypass

Thông số kỹ thuật:

1150 W HIGH OUTPUT LED MOVING HEAD WASH
