LIGHT SOURCE

• 1150 W proprietary LED light engine
• 84 x 20 W white LEDs
• Minimum LED lifetime: >50,000 hours (see specs for further details)

PHOTOMETRIC DATA

• Light Engine Luminous Output: 90,000 lumens
• Fixture Luminous Output: 63,500 lumens
• Peak Luminous Intensity: 5,000,000 cd
• CCT: 6000 K (+/- 250 K)

OPTICS

• 220 mm Front Lens
• 1:7 zoom range (6.8° - 47.5° beam angle)

DYNAMIC EFFECTS

• 0 - 100% continuous dimming and strobe effects
• Choice of four dimming curves
• CMY color mixing
• Color temperature control (6000 - 2850 K)
• Color wheel with six interchangeable dichroic filters, including a Spectral Enhancement Filter
• 1:10 Zoom (hyper zoom); 1:7 Zoom (native zoom)
• Motorized frost
• Iris
• Variable edge control
• Pan: 540°
• Tilt: 268°
• P3 videomapping of fixture color and/or intensity (10 segments)
• Pre-programmed effects: Two ranges of pre-programmed FX

COOLING AND NOISE

• Low noise cooling system
• User-selectable output vs. sound level control

CONSTRUCTION

• Height (head straight up): 848 mm (33.4 in.)
• Height (maximum): 867 mm (34.2 in.)
• Weight: 39.0 kg (86.0 lbs.)

CONTROL

• DMX-512 in/out
• Ethercon in/out for P3, Art-Net, sACN
• Built in Ethernet switch with fail-safe bypass
